Ceramic and cermet cutters and inserts have become increasingly popular in the machining industry due to their ability to withstand high temperatures and their exceptional hardness. These properties make them suitable for high-speed cutting and machining of hard materials such as hardened steels and superalloys. However, despite their advantages, there are several disadvantages associated with the use of ceramic and cermet cutters and inserts. Understanding these drawbacks is crucial for making informed decisions in machining operations.
One of the primary disadvantages of ceramic and cermet cutters is their brittleness. Unlike carbide inserts, which can absorb some degree of shock and vibration, ceramic and cermet materials are much more prone to cracking and chipping. This brittleness makes them unsuitable for applications involving interrupted cuts or operations where the tool is subjected to sudden impacts. For instance, in milling operations where the tool repeatedly enters and exits the workpiece, ceramic inserts are at a higher risk of fracturing.
To mitigate this issue, manufacturers often reinforce ceramic materials with silicon carbide whiskers, which act like fibers to enhance the toughness of the ceramic matrix. However, even with these reinforcements, ceramic cutters remain more fragile compared to carbide tools. This limitation necessitates careful handling and specific machining conditions to prevent premature tool failure.
Ceramic and cermet cutters are highly sensitive to thermal shock, which occurs when there is a rapid change in temperature. This sensitivity can lead to cracking or chipping of the cutting edge. In machining operations, thermal shock can occur when coolant is applied inconsistently or when the tool transitions between cutting and non-cutting phases. For example, in interrupted cutting operations, the tool repeatedly heats up during cutting and cools down when not in contact with the workpiece, leading to thermal cycling that can damage the tool.
To reduce the risk of thermal shock, it is essential to maintain a consistent application of coolant or, in some cases, to avoid using coolant altogether. However, this approach can limit the versatility of ceramic and cermet tools, making them less suitable for certain machining environments where coolant is necessary to control workpiece temperature and chip evacuation.
While ceramic and cermet cutters excel in high-speed machining of hard materials, their application range is relatively limited compared to carbide tools. Ceramics are particularly effective for machining hard ferrous materials and nickel-based superalloys but are less suitable for softer materials or those with lower hardness levels. For instance, ceramics are not recommended for machining ferrous materials with hardness below 42 Rc due to potential reaction problems.
Cermets, which are a combination of ceramic and metallic materials, offer a broader range of applications compared to pure ceramics. However, they still fall short of the versatility offered by carbide tools. Cermets are primarily used for finishing operations and are less effective in roughing or heavy-duty machining tasks.
The cost of ceramic and cermet cutters and inserts is generally higher than that of carbide tools. This higher cost is attributed to the complex manufacturing processes involved in producing these materials. For example, ceramic inserts undergo a hot pressing process that uses external heat and high pressure to eliminate porosity and achieve the desired hardness. Additionally, grinding and shaping ceramic materials require specialized equipment and techniques, further increasing production costs.
Moreover, ceramic and cermet tools offer limited opportunities for regrinding or reconditioning. Once the cutting edge is worn or damaged, the tool often needs to be replaced entirely, leading to higher tooling costs over time. This limitation makes ceramic and cermet tools less cost-effective for applications where frequent tool changes are required.
The wear patterns of ceramic and cermet cutters differ significantly from those of carbide tools. Ceramic inserts, for example, tend to show flaking along the cutting edge due to the pressures caused by flank wear. While this flaking can expose a new, sharper edge in roughing operations, it can also lead to unpredictable tool performance and reduced surface finish quality in finishing operations.
Cermet tools, on the other hand, are more chemically inert than carbide, reducing the likelihood of edge buildup and crater wear. However, they still face challenges in maintaining consistent wear patterns, especially in applications involving high temperatures and aggressive cutting conditions. The need to balance wear resistance with toughness often results in trade-offs that can affect tool life and performance.
Machining with ceramic and cermet cutters places significant demands on the machine tool. High cutting forces, aggressive feeds, and high spindle speeds are required to achieve optimal performance with these materials. As a result, the machine tool must be in excellent condition, with well-maintained lubrication systems, spindle bearings, and linear way systems. Any looseness or backlash in the machine tool motion can lead to vibrations that are detrimental to ceramic and cermet cutters.
Additionally, the tool holder and setup must be rigid to minimize deflections and vibrations. The shortest possible overhang and the use of thick tool shanks or boring bars are recommended to enhance stability during machining. These stringent requirements can limit the use of ceramic and cermet cutters to specific machine tools and setups, reducing their overall flexibility in a manufacturing environment.
While ceramic and cermet cutters and inserts offer significant advantages in terms of hardness, heat resistance, and high-speed machining capabilities, they also come with several disadvantages. Their brittleness, sensitivity to thermal shock, limited application range, higher costs, unique wear patterns, and stringent machine tool requirements are important factors to consider when selecting cutting tools for machining operations. By understanding these drawbacks, manufacturers can make informed decisions and optimize their machining processes to achieve the best possible outcomes.
