Swing over bed: 500mm, 660mm, 800mm Spindle Bore: 82mm
| Quantity: | |
|---|---|
Product Introduction of Horizontal Parallel Lathe
What we offer is a kind of trust.
We have a professional R&D team, overseas sales team, documentary team, lorry team, customs clearance team, team for shipping, aftersales team and professional business partner we can rely on.
They are manufactured following rules of ISO and CE stipulation.We have reference customer in over 40 nations, Such as Siemens, ITT, Hanwha, CRRC, Bombardier ....
Products Specification of Horizontal Parallel Lathe
Model NO. | CJ6250YB | CJ6266YB | CJ6280YB |
Swing over bed | Φ500mm(20’’) | Φ660mm(26’’) | Φ800mm(31’’) |
Swing over carriage | Φ300mm(12’’) | Φ420mm(17’’) | Φ560mm(22’’) |
Max. Swing in gap | Φ710mm(28’’) | Φ870(34’’) | Φ1010(40’’) |
Max. Length of workpiece | 1000/1500/2500/2000/3000/4000mm | ||
Effective gap length | 230mm | ||
Bed width | 405mm | ||
Spindle bore | Φ82mm | ||
Spindle taper of bore | |||
Spindle number speed | 24 steps | ||
Spindle range of speed | 9-1600rpm | ||
Threads metric pitches | 0.5-224mm/48 kinds | ||
Threads imperial pitches | 72-1/8TPI/46 kinds | ||
Thread diametral pitches | 56-1/4D/45 kinds | ||
Threads module pitches | 0.5-112mm/42 kinds | ||
Range of feeds longitudinal | 0.028-6.43mm(0.001’’-0.2392’’) | ||
Range of feeds cross | 0.012mm-2.73mm(0.004’’-0.1032’’) | ||
External diameter of the tailstock quill | Φ75mm | ||
Max. Traverse of the tailstock quill | 150 | ||
Quill taper | NO. 5 (morse) | ||
Max. Travel of compound rest | 145mm | ||
Max. Cross slide travel | 360mm | ||
Max. Size of tool shank(WxH) | 25x25mm | ||
Power of main motor | 7.5kW/9kW | ||
Over all size(LxWxH) | 2700/3200/3700/4200/5700)x1150x1800mm | ||
Net weight: | 2850-5300kg | ||
