Feature of CNC Mechanical Lathe
This CNC Mechanical Lathe is mainly used for processing various shaft , disk parts , turning can be all kinds of screw thread , arc , cone ,and plane of internal and external surface , can satisfy the ferrous and non-ferous metals the speed requirement of high-speed chip. Suitable for cars , motorcycles, electronics , aerospace , military industry and other industries to high efficiency , large quantity and high precision of parts processing . Machining precision can reach level 7.
Datails of CNC Mechanical Lathe
SPECIFICATIONS | Units | CK6150V | CK6150D | CK6150 |
Swing over bed | mm | 500 | 500 | 500 |
Swing over cross slide | mm | 250 | 250 | 260 |
Distance between centers | mm | 1000/1500/2000 | 750/1000/1500/2000 | 750/1000/1500/2000 |
Spindle bore | mm | 82 (Opt. 130) | 52 | 52(Opt. 80) |
Spindle bore taper | - | Metric 90/1:20 | MT6 | MT6 |
Spindle nose type | - | A2-8(Opt.A2-11) | C6 | C6 |
Spindle speed steps | - | Stepless | Manual 2 steps | Manual 2 steps(Optional: stepless) |
Spindle speed range | rpm | 1800 (Opt. 800) | L:70-700 H:160-1600 | L:100-500 H:500-1800 (Optional 90-1800) |
Turret/tool post | - | Electric 4 position | Electric 4 position | Electric 4 position |
Tool size | mm | 25 x 25 | 20*20 | 25*25 |
X axis travel | mm | 300 | 300 | 280 |
Z axis travel | mm | 750/1000 | 750/1000/1500/2000 | 750/1000/1500/2000 |
X axis rapid traverse | mm/min | 6000 | 6000 | 6000 |
Z axis rapid traverse | mm/min | 10000 | 8000 | 8000 |
Tailstock quill diameter | mm | Φ60 | 65 | 65 |
Tailstock quill taper | - | MT5 | MT4 | MT5 |
Tailstock quill travel | mm | 200 | 140 | 130 |
Main spindle motor | kw | 7.5 | 5.5 | 5.5 |
Coolant pump motor | kw | 0125 | 0.125 | 0.09 |
Weight for 550 | kg | 1700 | ||
Weight for 750 | kg | 1700 | 1900 | |
Weight for 1000 | kg | 2000 | 2000 | 2000 |
Dimension for 500 | mm | |||
Dimension for 750 | mm | 2200*1600*1700 | 2200*1700*1750 | |
Dimension for 1000 | mm | 2950*1700*1800 | 2500*1600*1700 | 2500*1700*1750 |
