ZJ Brand Thousands of Radial Drilling Machine was sold per year The Radial Drilling Machines has history of 70 years.. Model NO. Z3040x12, Z3040x16,Z3050x12,Z3050x16,Z3063x20,Z3080x25,Z30100x31,Z30125x40
| Quantity: | |
|---|---|
The main features of Radial Drill Machine
1. Radial drilling machine is provided with hydraulic presetting speed shift mechanism to save auxiliary time.
2. It only needs one handle to operate clockwise rotation, stop (brake), variable speed and neutral gear conveniently.
3. Spindle box, rocker arm, inner and outer posts are reliably clamped by hydraulic diamond clamping mechanism.
4. Perfect safety protector and outer post protection are available.
5. In design and production of structure, it further adopts a series of effective measures to prolong precision durability and lifespan of whole machine.
6. Its electrical equipment completely contributes to personal safety, reliability, long service life and convenient maintenance.
7. With wide range of speed and feed, with manual, power & fine feeds. The feed of machines are very easily engaged & disengaged at any time.
8. With safe and reliable feed safety machine, all parts easy operation and change.
9. All controls centralized on the head stock easy operation and change. Clamping for assemblies and speed change of spindle achiered by hydraulic power.
10. Integrating technology for casting parts is excellent, adopting casting equipment, ensuring high quality of materia for basic parts.
11. Spindle parts are made by special high quality steel heat treatment to be made by first class equipment, nsuring high strength and durability.
12. Main gears are machined by gear grinding, the machine ensuring high precision and low noise.
Parameter
Model | Unit | Z3050x12/1 | Z3050x16/1 | Z3063x20/1 | |
Max. Drilling diameter | mm | 50 | 50 | 63 | |
Distance between spindle axis and column | Max. | mm | 1250 | 1600 | 2000 |
Min. | mm | 350 | 350 | 450 | |
Distance between spindle nose and working surface of machine base | Max. | mm | 1220 | 1220 | 1600 |
Min. | mm | 320 | 320 | 400 | |
Spindle Travel | mm | 315 | 315 | 400 | |
Spindle taper | - | Morse 5# | Morse 5# | Morse 5# | |
Speed range of spindle | m/min | 25-2000 | 25-2000 | 20-1600 | |
Steps of spindle speed | step | 16 | 16 | 16 | |
Feed range of spindle | mm | 0.04-3.2 | 0.04-3.2 | 0.04-3.2 | |
Steps of spindle feed | step | 16 | 16 | 16 | |
Worktable dimension | mm | 630x500x500 | 630x500x500 | 800x630x500 | |
Max.torque of spindle | Nm | 500 | 500 | 980 | |
Lifting distance of swing arm | mm | 580 | 580 | 800 | |
Machine weight | kg | 3000 | 3500 | 7000 | |
Size(LxWxH) | mm | 2500x1070x2840 | 2500x1070x2840 | 3080x1250x3205 |
Operating
1. Machine match with English version manual instruction
2. Provide online support, like whatsapp,video conference and phone call (guide step by step)
Training
1. Training in Manufacturer workshops (for free)
2. Training in buyers company (for charge,normally two or three days needed )
1st day: inspection cable connection,the finished foundation is qualified guide customer know each components name and functions as well
2nd day: demo and teach user do calibration(vetical+honrizontal+Mathematical+ Physical mode) use customer workpieces do dynamic balance See the buyer operating the machine separately
3rd day: review all operation step and learn each parts maintenance method.
Troubleshooting
1. Before delivery :Special QC department check carefully ensure all is qualified with high quality
2. Through see customer actual photos or short video, using discussed group or email or video meeting or phone call give solutions immediately
3. Use remote monitor to inspection
4. Dispatch engineer go to customer workshops onsite
Maintenance
1. During the warranty: free replace the Damaged or broke part by non-human causes
2. Over warranty :just pay components cost price, we have safety stock for all parts
3. Software updated lifetime for free when Manufacturer have new vesion
4. For simple operation issue, through whatsapp/video/phone call deal with directly
5. For difficult issue, invite engineer to help you repair or debugging onsite
6. We also can provide 365 days 24 hours online technical support
