Thousands of Radial Drilling Machine was sold per year Model NO. Z3040x12, Z3040x16,Z3050x12,Z3050x16,Z3063x20,Z3080x25,Z30100x31,Z30125x40 ---Original ZJ Brand
| Quantity: | |
|---|---|
Introduction of Radial Drilling Machine Z3050x16/1
• All machine tools adopt HT200-HT300 high-strength cast iron.
• The overall style adopts a new green appearance, with bright colors, concise and generous, and a partial design that is more user-friendly, convenient, and comfortable to operate.
•The guideway surface and the column raceway are all quenched or inlaid with steel, which is more durable and prolongs the life of the machine tool.
•The spindle box, rocker arm, inner and outer columns are clamped by hydraulically driven diamond blocks and the speed change performance is reliable.
• All the control handles are placed in a convenient location, and easy to operate
The five actions of spindle forward and reverse, parking (brake), shifting, and neutral are all controlled by a handle, which is easy to use.
All gears are made of national-standard steel and processed according to related processes. They are also ground, which makes them durable and noise-free.
•Hydraulic parts are all manufactured according to the standard of gold products.
• All electrical components use Siemens and Schneider accessories, which are more stable and reliable.
•The bearing uses standard Harbin shaft products, and some key parts adopt Japanese NSK bearings.
• The spindle uses 58cr, a special customized material for rotary drilling.
The interior of the headstock, the rocker arm, and the column are all automatically lubricated. The rocker arm guide rail and the rocker arm lifting mechanism are lubricated manually.
Parameter of Z3050x16/1 Radial drilling machine
Model | Unit | Z3050x16/1 | |
Max. Drilling diameter | mm | 50 | |
Distance between spindle axis and column | Max. | mm | 1600 |
Min. | mm | 350 | |
Distance between spindle nose and the working surface of the machine base | Max. | mm | 1220 |
Min. | mm | 320 | |
Spindle Travel | mm | 315 | |
Spindle taper | - | Morse 5# | |
Speed range of spindle | m/min | 25-2000 | |
Steps of spindle speed | step | 16 | |
Feed range of spindle | mm | 0.04-3.2 | |
Steps of spindle feed | step | 16 | |
Worktable dimension | mm | 630x500x500 | |
Max.torque of spindle | Nm | 500 | |
Lifting distance of swing arm | mm | 580 | |
Machine weight | kg | 3500 | |
Size(LxWxH) | mm | 2500x1070x2840 |
Precision of
S/N | Item | Tolerance |
1 | Flatness of the working surface of the base | At 1000 measuring length: 0.10 flat or concave |
2 | Parallelism of the headstock movement to the working surface of the base | The measurement length at any 1000 is: 0.30 |
3 | Parallelism of the rocker arm movement to the working surface of the base | Measuring length at any 300: 0.05 |
4 | 1. Radial runout of the axis of the spindle taper hole: | 1：0.02 2：0.04 |
5 | 1. Close to the end face of the spindle | 0.20/1000* *Indicator probe measuring contact distance |
6 | 2. 300 points away from the end face of the spindle | A 0.10/300 B 0.05/300 |
7 | The perpendicularity of the spindle axis to the working surface of the base | A0.06 B0.10 |
8 | The verticality of the working surface of the spindle vertical movement base | Load value (feed resistance) 15200Na.b3/1000 The distance between the two contacts of the indicator |
Benefit:
1. High precision drilling holes.
2. Increasing working efficiency
3. 7x24 hour on line service
Details of Z3050 radial arm drilling machine
Operating
1. Machine match with English version manual instruction
2. Provide online support, like whatsapp,video conference and phone call (guide step by step)
Training
1. Training in Manufacturer workshops (for free)
2. Training in buyers company (for charge,normally two or three days needed )
1st day: inspection cable connection,the finished foundation is qualified guide customer know each components name and functions as well
2nd day: demo and teach user do calibration(vetical+honrizontal+Mathematical+ Physical mode) use customer workpieces do dynamic balance See the buyer operating the machine separately
3rd day: review all operation step and learn each parts maintenance method.
Troubleshooting
1. Before delivery :Special QC department check carefully ensure all is qualified with high quality
2. Through see customer actual photos or short video, using discussed group or email or video meeting or phone call give solutions immediately
3. Use remote monitor to inspection
4. Dispatch engineer go to customer workshops onsite
Maintenance
1. During the warranty: free replace the Damaged or broke part by non-human causes
2. Over warranty :just pay components cost price, we have safety stock for all parts
3. Software updated lifetime for free when Manufacturer have new vesion
4. For simple operation issue, through whatsapp/video/phone call deal with directly
5. For difficult issue, invite engineer to help you repair or debugging onsite
6. We also can provide 365 days 24 hours online technical support
