CBN Inserts WNMG 080404 080408 080412 WNGA 080404 431 432 Boron NitridePCBN Tipped Insert Lathe Turning tools
| Quantity: | |
|---|---|
CBN Inserts WNMG 080404 080408 080412 WNGA 080404 431 432 Boron NitridePCBN Tipped Insert WNGA Lathe Turning Tool
Products Parameters:
01. Brand Name: EDGEV
02. Description: 80 Degree Trigon Negative CNC Soldering WNGA Lathe Turning Tool
03. ISO Specification:
WNGA080404 S01020 ESBN200 For Hardened Steel
WNGA080408 S02020 ESBN200 For Hardened Steel
WNGA080404 S01020 ESBN500 For Cast Iron
WNGA080408 S02020 ESBN500 For Cast Iron
04. ANSI Specification: WNGA431/WNGA432
05. Material: Cubic Boron Nitride
06. Grade: ESBN200 and ESBN500
07. Features: Excellent wear resistance and excellent impact and shock resistance
08. Application: Suitable for continuous and interrupted turning and milling with high cutting speed of alloy steel, hardened steel and bearing steel and cast iron.
09. Work Piece Hardness: HRC45~65
10. Suitable Work Piece: Break disc, Belt pulley, Gear, Bear, Metallurgical roll, Pump, Mining machinery, Brake drum, Brake disc, Metallurgical roll, Big gear, Slewing bearing industry, Gearing industry, bearing industry
11. Color: Black
12. Usage: External Turning Tools
13. Application Range: From Finishing to Semi-finishing
14. Suitable Tool Holder: MWLNR/L PWLNR/L WWLNR/L DWLNR/L
15. Place of Origin: China
16. Mini Order: 1 Piece/Box
17. Net Weight: 12g/Piece
18. Packing: Plastic Box
