CCMT0602 Turning Inserts

EDGEV 2 PCS PCD Insert CCMT060202/04 CCMT09TM02/04 CCMT120402/04/08 CCMT Diamond Inserts Lathe Cutter CNC Tools

Products Details:

01.Brand Name: EDGEV

02.Description: PCD Tipped Inserts

03.ISO Specification:

CCMT060202 FNNF (Radius Corner:0.2mm)
CCMT060204 FNNF (Radius Corner:0.4mm)
CCMT09T302 FNNF (Radius Corner:0.2mm)
CCMT09T304 FNNF (Radius Corner:0.4mm)
CCMT09T308 FNNF (Radius Corner:0.8mm)
CCMT120402 FNNF (Radius Corner:0.2mm)
CCMT120404 FNNF (Radius Corner:0.4mm)
CCMT120408 FNNF (Radius Corner:0.8mm)

04.Inch Specification:

05.Material: PCD

06.Chamfer Land: F-sharp edge

07.PCD Grade:
Economic Types are from EDGEV Grade
Power Quality Type are from GE or E6 Grade Material

08.Color: Black

09.Application Range: For Finishing to Semi-finishing Roughing

10.Available Tool Holder:

11.Place of Origin: China

12.Mini Order: 2 Pieces/Box

13.Net Weight: 30g/Piece

14.Gross Weight: 50g

15.Packing: 2 Pieces Packed In One Plastic Box /lot

16.Delivery Time:30 days

17.100% Inspected before the products are shipped out.

Please Attention: Unit price is 2 pieces of price, Please kindly notice;

How to Identify Edge Preparation?

1.Symbol: F, That means is Sharper Edge, applied for finishing

2.Symbol: T, That means is Chamfered Edge, applied for finishing to semi-finishing, for example:T00520(0.05mm*20 degree)

3.Symbol: S, That means is Chamfered and honed Edge, applied for roughing to semi-finishing, for example:S01020(0.1mm*20 degree)
