Featurer of CNC Vertical Lathe with C Axis

Feature of CNC Double Column Vertical Lathe with C Axis

1. Introduction of machine tool:

This series of double-column vertical turning and milling machine is our company absorbs contemporary advanced design and manufacturing technology, adopts finite element analysis calculation and optimization design methods, implements the latest national precision standards, configures advanced functional components at home and abroad, realizes strong cutting in structural performance, high dynamic and static rigidity of machine tools, safe and reliable movements, long service life and high processing efficiency of high-tech mechatronics machine tools.

This machine tool has 1 spindle (milling spindle), X, Z, C three feed axes, for three-axis linkage multi-functional, high-efficiency CNC double-column vertical turning and milling machine.

2. Main use and scope of application

This machine tool is suitable for high-speed steel, cemented carbide and ceramic tools, rough and finishing of parts made of various ferrous metals, non-ferrous metals and some non-metallic materials, and can complete the turning of internal and external cylindrical surfaces, internal and external conical surfaces, end faces, grooving, metric thread and rotary surfaces and other processes.

Milling, boring, drilling, tapping functions

It can complete the drilling, tapping, boring, milling plane and outer circular plane, holes with small boring depth, and milling keyways on the inner and outer cylindrical and end faces of parts.

Indexing function

The table has a circumferential milling feed function during milling, and the table has an indexing function when drilling, tapping and boring at any position.
