Single Column Vertical Lathe with C Axis for Turning, Milling, Boring, Tapping, Drilling

l Siemens 828D system, with 15'' colorful TFT display

l Main machines parts, such as columns, cross beam, worktable etc adopt Vibration-absorbing cast iron, which ensure machine rigidity and long service life

l The worktable base with Siemens encoder, and manual 4 jaw chuck for workpiece clamping

l Adopt square ram, the ram size is 200x200mm, the ram material is forging structure.

l X axis adopt linear guideway which improve positioning accuracy and re-positioning accuracy. Z , W axis adopt slide guideway.

l The worktable with C axis indexing function

l Automatic lubrication system

l Semi- protection cover

l With cooling system

l With chain type chip conveyor

l Electrical cabinet with air conditioner

l With working light

l With three color indicator

l The milling spindle with Encoder

l Spindle oil cooler

l Function: Turning, drilling, tapering and milling
