Fixed Beam Double Column Vertical Lathe

Views: 0     Author: Site Editor     Publish Time: 2025-07-24      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

CNC fixed beam double column vertical lathe

The CKD5235 CNC fixed-beam double-column vertical lathe is a product developed by our company after years of user surveys. We have organised multiple expert analyses of machining processes and the special requirements these processes place on machine tools, specifically targeting the machining characteristics of large ring-forged parts. optimising the machine tool's structure and configuration to prioritise specialisation, processing efficiency, and processing quality. This has resulted in a significant increase in the processing efficiency of large ring-forged parts.

The CKD5235 CNC fixed-beam double-column vertical lathe is a dual-toolpost heavy-cutting machine tool designed for the rough and semi-finish machining of large ring-forged parts.

The CKD5235 CNC fixed-beam double-column vertical lathe features a high-rigidity, long-span guide rail beam, a long-guide, large-section square slideway tool holder, a high-load, large-diameter hydrostatic guide rail worktable, a high-torque servo spindle motor, and a large-module II-speed gearbox, significantly enhancing machining efficiency.

The right tool post of the CKD5235 CNC fixed-beam double-column vertical lathe is controlled by the Siemens 828D CNC system, while the left tool post is controlled by the Beijing Super Synchronous Programmable Control System. This configuration not only provides powerful cutting capability and high-quality machining accuracy but also ensures high stability.

The CKD5235 CNC fixed-beam double-column vertical lathe incorporates contemporary advanced design concepts, employs CAD-optimised design methods, complies with the latest national standards, and is equipped with advanced functional components from both domestic and international sources. It achieves powerful cutting and high-precision machining in terms of structural performance, features a powerful workbench drive, and boasts high dynamic and static rigidity. It is a high-tech mechatronic product with reliable performance, a long service life, and high machining efficiency.


Starfish Ruhr Heavy Machinery Technology (Dalian) Co.,Ltd started with lathe machine tool. Senior engineer and chief engineer with 35-45 years working experience in machine tool industry. Starfish Machinery is specializing in vertical lathe,vertical lathe with milling function, horizontal lathe, Boring milling machine, welding boom column
