CXK5225, CKX5131, CXK5240, CKX5250, CXK5263, CXK5280, CXK52100, CXK52125
| Quantity: | |
|---|---|
Introduction
This CXK52 series of CNC Double Column Vertical Turning Milling Lathe Lathe is adopted finite element analysis calculation and optimization design methods, implements the latest national precision standards, configures advanced functional components at home and abroad, realizes strong cutting in structural performance, high dynamic and static rigidity of machine tools, safe and reliable movements, long service life and high processing efficiency of high-tech mechatronics machine tools.
This large live tool vertical lathe has 1 spindle (milling spindle), three or five axes,
For high-efficiency CNC vertical lathe with c axis for turning, milling, drilling, boring, taping.
Details
Parameter
The parameters of the Vertical Turning and Milling Lathe can be customized
| Item | Unit | CXK5225 | CXK5235 | CXK5240 | CXK5250 |
| Max. Worktable diameter | mm | 2500 | 3500 | 4000 | 5000 |
| Max. Workpiece height | mm | 1600/2000/2200 | 1600/2000/2500 | 1600/2000/2500 | 1600/2000/4000 |
| Worktable diameter | mm | 2250 | 2850 | 3150 | 4500 |
| Max. loading weight | t | 10/16 | 10/16/20/32 | 10/16/32 /40/50/63 | 32/40/50 /63150 |
| Worktable rotation step | stepless | stepless | stepless | stepless | |
| Worktable rotation speed | r/min | 2~63 | 2~63 | 2~63 | 0.32~32 |
| Max. Worktable torque | KN·m | 63 | 63 | 63 | 150 |
| Main motor power | kW | 55 | 55 | 55 | 75/90 |
| Weight | t | 41 | 45 | 47 | 200 |
| Item | Unit | CXK5263 | CXK5280 | CXK52100 | CXK52125 |
| Max. Worktable diameter | mm | 6300 | 8000 | 10000 | 12500 |
| Max. Workpiece height | mm | 3500/4000/5000 | 3500/4000/5000 | 4000/5000/6000 | 4000/5000/6000 |
| Worktable diameter | mm | 5700 | 7100 | 7500 | 7500 |
| Max. Worktable weight | t | 63/80/100/150 | 100/125/150 | 150/250 | 250 |
| Worktable rotation step | stepless | stepless | stepless | stepless | |
| Worktable rotation speed | r/min | 0.32~32 | 0.32~32 | 0.2~20 | 0.16~16 |
| Max. Worktable torque | KN·m | 150 | 150 | 640 | 640 |
| Main motor power | kW | 90 | 90/132 | 132 | 132 |
| Weight | t | 215 | - | - | 465 |
Product Advantage
1. Gantry frame
The gantry comprises a left column, a right column, a connecting beam, a worktable, etc. It is connected to the foundation of the heavy-duty vertical lathe with a live tool Closed symmetrical frame, using high-strength low-stress cast iron, with sufficient rigidity and strength to ensure the accuracy of the vertical turning lathe with long-term retention and stability.
2. Crossbeam
The beam is placed in front of the column, driven by a double-shaft extension AC motor, and driven by gears, worm gears, and lead screws to make the beam move vertically on the column
3. The worktable adopts
A fixed-spindle-type short-spindle structure. A set of high-precision (P5) double-row short cylindrical roller bearings is installed on the spindle of the CNC Vertical Turning Milling Lathe
4. Vertical tool holder
This equipment is equipped with a tool holder designed for CNC turning and milling applications.
Product Uses
The Heavy Duty Double Column Vertical Lathe with C axis is suitable for high-speed steel, cemented carbide and ceramic tools, rough and finishing of parts made of various ferrous metals, non-ferrous metals and some non-metallic materials, and can complete the turning of internal and external cylindrical surfaces, internal and external conical surfaces, end faces, grooving, metric thread and rotary surfaces and other processes.
FAQ
Acceptance:
The content of pre-acceptance by the standard of machine acceptance
and a precision inspection sheet.
Installation
1) The buyer, according to the foundation chart, was offered by the seller.
2) After the equipment arrives at the user site, the buyer needs to complete the preparations for the three-phase power supply, three-phase four-core cable, compressed air source, etc., and provide the cables as mentioned above and air pipes to enter the standard interface of the machine tool, and the user will notify the supplier to install and debug after the preparation is ready.
Training
• 1-2 days: Inspection of cable connection, the finished foundation is qualified to guide the
customer to know each component's name and functions as well.
1) Demo and teach the user to calibrate and use customer workpieces in the machine.
Review all operation steps and learn each part's maintenance method.
Warranty period is 14 months from the date of debugging in the customer workshop.
In the warranty period
If some parts need to be replaced due to the quality of the product, the company is responsible for free replacement. If the issue is not related to the product quality of the Vertical Lathe, or if the company needs to send a technician to fix the Vertical Lathe, the appropriate fees should be collected.
Our company will assist customers in getting the machine running well and answer all questions
from customers online.
For simple operation issues through email/WhatsApp/video/phone call deal with directly
For a difficult issue, invite an engineer to help you repair or debug onsite.
Out of warranty period:
The customer just pays the cost of parts at a reasonable and lower price.
Troubleshooting
1) Before delivery: The Special QC department carefully checks to ensure that all is qualified with high
quality
2) Through seeing customers' actual photos or videos, using the discussed group or email, or video
meeting or a phone call gives solutions immediately
3) The dispatch engineer goes to customer workshops onsite.
