CKD5255X10/50 CNC fixed-beam double-column vertical lathe

CKD5255X10/50 CNC fixed beam double column vertical lathe is based on many years of user surveys, for the processing of large ring-forged parts, many times to organise relevant experts to analyse the processing technology and special requirements for machine tool machining, for the user to process the parts of the process characteristics, to optimise the structure and configuration of the machine tool, so that the CKD5255X10/50 CNC fixed-beam double-column vertical lathe focuses on the speciality and processing efficiency and processing quality, so that the processing efficiency has been doubled. The speciality, processing efficiency and processing quality of CKD5255X10/50 CNC double-column vertical lathe are more focused on speciality and processing efficiency and processing quality, so that the processing efficiency of large-sized ring forging workpieces can be multiplied.

CKD5255X10/50 CNC fixed-beam double-column vertical lathe is a double-tool holder heavy-duty machine tool suitable for roughing and semi-finishing machining of large-sized ring-forged parts.

CKD5255X10/50 CNC fixed-beam double-column vertical lathe greatly improves the machining efficiency due to the adoption of high rigidity and large span guideway crossbeam, long guiding and large cross-section ram tool holder, high load-bearing and large-diameter static guideway table, high-torque servo spindle motor, and large-module Ⅱ gearbox; the table of CKD5255X10/50 CNC fixed-beam double-column vertical lathe with double tool holder is equipped with High-precision encoder can realise constant speed cutting.

CKD5255X10/50 CNC fixed-beam double-column vertical lathe adopts Siemens CNC system for the right tool rest and Beijing Ultra-Synchronous Programmed Control for the left tool rest, which not only has strong cutting ability and high-quality machining accuracy but also has high stability.

CKD5255X10/50 CNC fixed-beam double-column vertical lathe draws on the contemporary advanced design concept, adopts CAD optimisation design method, implements the latest national standards, is equipped with domestic and foreign advanced functional components, and realises powerful cutting and high-precision machining in terms of structural performance, with strong power of the worktable, high dynamic and static rigidity of the machine tool, safe and reliable performance, long service life and high machining efficiency. It is a high-tech electromechanical-hydraulic integrated product.
