This series of machine is of genenal-purpose, suitable for such operation as drilling, counter-boring,boring,reaming,spot-facing,tapping and milling etc. The horizontal milling and boring Machine type is equipped with fixed facing plate on which radial facing slide can be radically feed consequently to enable the machine to undertake boring of large-diameter hole, external cutting, end face turning and recessing, etc.
The products are easy to find and available in many stores. We glance forward to receiving your enquires shortly and hope to have the opportunity to function along with you inside the future. Welcome to acquire a glimpse at our organization.
Feature of Table Boring Mills
1) The speed change of main motion and feed motion of the machine are all adopted hydraulic pre-selection centralized control.
2) The vertical coordinate (headstock lifting direction) and cross coordinate and longitudinal coordinate are provided with new type Digital Display Unit with memory function, which make the machine with complete function and high accuracy.
3) Main parts of the Table Boring Mills such as bed, front column and guideways of lower saddle are all adopted electric-contract surface heating self-cooling harden, which bring high stiffness of the guideways and extend the using life of the machine.
4) Materials forbidden to cut: non-metal material, i.e. graphite, stone; material with low rigidity that cannot be clamped or fixed; metal with low igniting point, i.e. magnesium alloy, etc.; poisonous or flammable material. This machine is suitable for using in practical environment under certain running condition
5) Electric-hydraulic interlocking device will be fixed between the moving units and when a moving unit is moving, the other moving units will be clamped automatically
Detail of Table Boring Mills
Products Specification of Table Boring Mills
Model | Unit | PB110 | PB130 | PB130H |
Spindle bore | mm | 110 | 130 | |
Spindle speed | rpm | 10-1200 ( 1500、2000、2500 ) | 10-1200(1500, 2000) | 7-1500 (2000) |
Motor power | kW | 18. 526 | 2230 | 25 |
Max. Spindle torqe | N.M | 16802000 | 20002700 | 2700 |
Worktable size | mm | 1250X1400(1400X1600) | 1400X1600 (1600X1800) | |
Max. Loading weight | T | 6(10、15) | 10、15 | |
X axis travel | mm | 2000 | ||
Y axis travel | mm | 1600 (2000) | 1600 (2000、 2500) | 1600 (2000、 2500、 3000) |
W axis travel | mm | 1250 (1500、 2000) | ||
W axis travel | 600 | 750 | 900 | |
Positioning precision XYZ W/B | mm | 0.025/10 | 0.025/10 | |
Re Positioning precision XYZ W/B | mm | 0. 020/7 | 0. 020/7 | |
Feeding speedXYZ /W/B | 4/2/1 | |||
Rapid travel XYZ /W/B | rpm | 8/4/2 | ||
Weight | T | 25 | 28 | 36 |
CNC system | Siemens, FANUC | |||
Package
Our goal is to provide high quality products at competitive prices, and top-notch service to customers around the world. We are ISO9001, CE, and GS certified and strictly adhere to their quality specifications for table boring mills, The product will supply to all over the world, such as: Irish, USA, Mali, Panama, After 13 years of researching and developing products, our brand can represent wide range of products with outstanding quality in world market. We have completed big contracts from many countries such as Germany, Israel, Ukraine, United Kingdom, Italy, Argentina, France, Brazil, and so on. You probably feel secure and satisfy when copperate with us.
